Ikegami BS-79 - Pin Assignment of Connectors

3. INSTALLATION AND CONNECTION 3 - 7
BS-79 0212 VOL1 (U) (E) BS-79
3.6 Pin Assignment of Connectors
[DC IN connector]
1
2
3
4
1
2
3
4
+12 V RET
+12 V RET
+12 V IN
+12 V IN
Use a dedicated DC cable (PSC574).+12 V input RET
+12 V input RET
+12 V input (10.8 to 16 V)
+12 V input (10.8 to 16 V)
RET
RET
IN
IN
This connector is used to connect an external DC power supply
(such as a deep cycle battery).
BS side : HA16RA-4P (Hirose)
Cable side : XLR-4-11C (4-pin female plug)
or equivalent
Insertion side
Pin Number Name Function Direction External Interface
Receptacle
[CAMERA connector]
• 3K series (SMPTE 30H type)
3
4
01
02
1
2
3
4
OPT H - B
OPT B - H
MTL (H) B - H
MTL (C) H - B
DC +160V (H)
DC +160V (C)
Optical contact camera head → BS
Optical contact BS → camera head
Control signal (H) BS → camera head
Control signal (C) camera head → BS
DC power supplied from the BS to the camera (H)
DC power supplied from the BS to the camera (C)
IN
OUT
OUT
IN
OUT
OUT
This connector is used to connect a camera head to the BS.
BS side : FXW.3K.93C.CLC (Lemo)
Cable side : PUW.3K.93C.CLMC96
or equivalent
Insertion side
Pin Number Name Function Direction External Interface
Receptacle
2 1
3 4
01
02
Guide mark
