IKUSI 2844 - ONE 118 Model (AFP-201); Technical Specifications

46
Technical specifications
ONE 118 Model (AFP-201)
Inputs
BI-FM
1
BIII-DAB
1
UHF1 UHF2 UHF3
3
Band width MHz 47-108 174-240 470-862
Input conguration
Number of programmable UHF
lters per input
- - 10 0 0
- - 9 0 1
- - 7 0 3
- - 2 5 3
- - 2 7 1
Gain dB 35 40
35 / 55
(switchable)
Gain adjustment dB 25 20 30
Noise gure dB <6 <6 <6
Optimum input margin dBµV 60-85 60-80
50-80
70-100
Return losses dB >10 >10 >10
Selectivity
(± 10 MHz of channel ends)
dB >10
Uncoupling between inputs dB - - >20
AGC tolerance dB - - ±1
Switchable preamp voltage V - - 0-12-24
Maximum preamp current mA - - 100
Output TV
Output level* dBµV 118 118 118
Output level adjustment dB 20
Return losses dB >10
Test outputs dB -30
Operations
Mains voltage 230 - 240 V~
Consumption 0.25 A / 25 W
Operating temperature -5 to 50 ºC
Mains connector IEC C8
* IMD3-60dB, DIN 45004B
(See channel reduction table in Technical Annex)
