IKUSI 2844 - ONE SAT Model (AFP-292)

Technical specifications / ONE SAT Model (AFP-292)
47
ONE SAT Model (AFP-292)
Inputs
BI-FM
1
BIII-DAB
1
UHF1 UHF2 UHF3
3
EXT
(VHF/UHF)
1
SAT-IF
1
FI-SAT
(passive)
1
Band width MHz 47-108 174-240 470-862
47-240 /
470-862
950-
2150
950-
2150
Input conguration
Number of programmable
UHF lters per input
- - 10 0 0 - - -
- - 9 0 1 - - -
- - 7 0 3 - - -
- - 2 5 3 - - -
- - 2 7 1 - - -
Gain
TV1&TV2 conf
TV1 conf
dB
30 35
35/55
(switchable)
35 40 -1.5
35 40
40/60
(switchable)
40 40
Gain adjustment dB 25 20 30 20 20 -
Noise gure dB <6 <6 <6 <6 <9 -
Optimum input
margin
dBµV 60-85 60-80
50-80
70-100
60-80 68-88 -
Return losses dB >10 >10 >10 >10 >10 >10
Selectivity
(± 10 MHz
of channel ends)
dB >10 - - -
Uncoupling
between inputs
dB - - >20 - - -
AGC tolerance dB - - ±1 - - -
Switchable preamp
voltage
V - - 0-12-24 - 0-13-18 -
Maximum preamp
current
mA - - 100 - 300 -
Preamp tones kHz - - - - 0-22 -
Slope adjustment dB - - - - 0-9 -
Outputs (2 options) TV+IF
Output
level*
TV1&TV2 conf
TV1 conf
dBµV
113 113 118 113/118 116 -
118 118 123 113/123 116
Output level
adjustment
dB 20 -
Return losses dB >10 -
Test outputs (2) dB -30
Operations
Mains voltage 230 - 240 V~
Consumption 0.25 A / 25 W
Operating temperature -5 to 50 ºC
Mains connector IEC C8
* Terrestrial: IMD3-60dB, DIN 45004B ; Satellite: IMD3 -35dB, EN50083-3.
(See channel reduction table in Technical Annex)
