IKUSI 2844 - General Equipment Use

34
Introduction / General equipment use
F
SAT1 gain = 40 dB.
F
SAT2 gain = -1.5 dB.
J
Outputs (2 congurable outputs):

a)
F
2 TV+FI outputs
F
2 Test outputs
F
VHF output level = 113 dBµV.
1
F
UHF output level = 118 dBµV.
1
F
FI/SAT output level = 116 dBμV.
2
b)
F
1 TV+FI output
F
1 Test output
F
VHF output level = 118 dBµV.
1
F
UHF output level = 123 dBµV.
1
F
FI/SAT output level = 116 dBμV.
2
1
Terrestrial: IMD3-60 dB, DIN 45004B
2
Satellite: IMD3 -35dB, EN50083-3. See channel reduction table in Technical Annex
ONE Home Model
Recommended for small installations made up of 10 UHF lters deli vering an output level
of 118 dBμV.
J
Inputs:
F
2 terrestrial inputs = BI-FM, UHF1
F
BI-FM gain = 2 dB.
F
UHF gain = 40 dB.
J
Outputs:
F
1 TV output.
F
1 Test output.
F
VHF/UHF output level = 113 dBµV.
1
1
IMD3-60 dB, DIN 45004B (see channel reduction table in Technical Annex)
General equipment use
Interaction with the equipment using the button and the interpreting of the instructions
displayed on the LCD screen are described below. The programme includes a main menu
formed by submenus that can be selected to modify the equipment operating settings.
Instructions displayed on the LCD screen
This symbol is displayed when manual setting is selected. It refers to the
clusters indicated on the panel.
