Operating manual - English ECODRILL 2000 C/E
11
3.1 Technical data
ELECTRICITY SUPPLY: 230V-50Hz / 100V-50/60Hz
MAXIMUM ABSORBED POWER: 1,1 Amp. 240 Watt / 1,7 Amp. 170 Watt
MOTOR: One-speed single phase
CUTTING TOOLS: Super rapid steel (HSS)
MOVEMENTS: on three axes
CLAMP: removable, with fixed and mobile interchangeable jaws
RUNS: X axis: 30 mm
Y axis: 50 mm
Z axis: 30 mm
DIMENSIONS: width: 350 mm depth: 420 mm height: 460 mm
MASS: Kg. 25
SOUND PRESSURE: Lp(A) = 78,2 dB(A)
3.2 Graphics
Fig. 5
THE USE OF PROTECTIVE GOGGLES
IS COMPULSORY
