Operating manual - English ECODRILL 2000 C/E
5
REFERENCE GUIDE
This manual has been produced to serve as a guide for users of the ECODRILL 2000 C/E key-cutting
machine. Read it carefully; it is essential if you wish to operate your machine safely and efficiently.
Consultation
The contents of the manual are divided into sections relating to:
- Transport and handling
- Checking the safety of the machine
- Proper use of the machine
- Maintenance
Technical terms
Common technical terms are used in this manual.
To assist those with little experience of keys and key-cutting, below is an illustration of the terms most
frequently used (fig. 1).
Fig. 1
1) Head
2) Rim
3) Stop
4) Stem
5) Tip
6) Back
7) Cuts
2
1
5
7
3
4
6
1
5
7
3
DIMPLE KEY LASER (SIDEWINDER) TYPE KEY
keys with holes of different
dimensions, depths, positions and
shapes.
LASER is the name given to the
special sidewinder milled keys.
