6.3 Tracer springing
You can obtain the tracer springing simply by turning the inferior ring nut (U) (fig.10) of the
holder tracer spindle, while doing so, keep the superior ring nut (N) fixed. So, you have:
- to turn left to obtain the springing
- to turn right to eliminate it
Fig. 10
N
U
without springing
springing
