3. Pull the knob from the cylinder.
4. Insert the knob removal tool into the front of the new knob. While holding the back of the knob, press
firmly on the tool until it clicks.
5. While pressing on the tool, slide the knob onto the cylinder until it stops.
NOTE! Make sure that the knob is inserted the correct way around so that the straight edges
of the cylinder and knob align horizontally.
22
Document ID - 304931
iLOQ S50 (X50S)
