iM3 Elite User Manual

4
iM3 elite Control Panel - Front
(A) Powerful suction handpiece and suction tip.
(B) 3 way air/water syringe.
(C) Handpiece pressure gauge.
(D) Selector water/CLS switch.
(E) Water flow control for high speed handpiece
(F) Low speed handpiece position.
(G) High speed handpiece position
(H) Magnetic bur holder.
(I) Corian top
(J) IEC power board on side of machine.
(K) Handpiece exhaust collection bottle 500ml
(L) Suction waste collection bottle 1000ml
(M) Coolant outlet for ultrasonic scaler (on back panel)
(N) On/Off pressure switch for coolant system (on back panel)
(O) IEC female outlet for main power supply 240v.
iM3 Dental Systems
A
D
L
J
C
B
F
G
H
E
I
iM3 elite Control Panel - Back
M
N O
K
L

iM3 Elite Specifications

General

Brand	iM3
Model	Elite
Category	Medical Equipment
Language	English
