What to do if the ImageQuest Q770 image is unstable?
To resolve an unstable image on your ImageQuest Monitor, inspect the 15 pin D-sub connector, cable, and ZDM01. Also, check ICM01 and ICH01, along with CH06 and RH06. If necessary, replace ICH01 and check RH10.
How to fix a scrolling image on an ImageQuest Monitor?
To address a scrolling image on your ImageQuest Monitor, inspect the 15 pin D-sub connector, cable, and ZDM02. Also, check ICM01 and ICH01, along with CH01 and CH02. If necessary, replace ICH01 and check B+ at pin 2,4 of ICV01.
General| Screen Size | 17 inches |
|---|---|
| Resolution | 1280 x 1024 |
| Aspect Ratio | 5:4 |
| Response Time | 25 ms |
| Brightness | 250 cd/m² |
| Connectivity | VGA |
| Panel Type | TN |
