ImageQuest Q770 - Thermal Protection

--36--
TDA9302H
HEPTAWATT
(Plastic Package)
ORDERCODE : TDA9302H
Flyback
Generator
Thermal
Protection
362
1
7
5
4
YOKE
+V
S
Power
Amplifier
TDA9302H
BLOCKDIAGRAM
.
POWER AMPLIFIER
.
FLYBACKGENERATOR
.
THERMAL PROTECTION
7
6
5
4
3
2
1
Tab connected toPin4
OUTPUTSTAGESUPPLY
OUTPUT
GROUND
FLYBACKGENERATOR
SUPPLY VOLTAGE
INVERTINGINPUT
NON-INVERTINGINPUT
PINCONNECTIONS(topview)
DESCRIPTION
The TDA9302His a monolithicintegrated circuit in
HEPTAWATT
TM
package.It is a high efficiency
powerbooster fordirectdriving ofverticalwindings
ofTVyokes. It is intended foruse inColor andB &
W televisionaswellas in monitorsand displays.
