--34--
4K 2.5V CMOS Serial EEPROMs
FEATURES
• Single supply with operation down to 2.5V
• Low power CMOS technology
- 1 mA active current typical
- 10µA standby current typical at 5.5V
- 5 µA standby current typical at 3.0V
• Organized as two or fore blocks of 256 bytes
(2
256 8) and (4 256 8)
• Two wire serial interface bus, 12CTM
• Schmitt tigger, filtered inputs for noise suppression
• Output slope control to eliminate ground bounce
• 100kHz (2.5V) and 400kHz (5V) compatibility
• Self-timed write cycle (including auto-erase)
• Page-write buffer for up to 16 bytes
• 2 ms typical write cycle time for page-write
• Hardware write cycle time for page-write
• Can be operated as a serial ROM
• Factory programming (OTP) available
• ESD protection > 4,000V
• 1,000,000 ERASE/WRITE cycles (typical)
• Data retention > 40 years
• 8-pin DIP, 8-lead or 14-lead SOIC packages
• Available for extended temperature ranges
- Commercial : 0°C to +70°C
- Industrial : -40°C to +85°C
KS24C08
