Horizontal Deflection Output For High Resolution Display, Color TV
High Speed Switching Applications
• High Voltage : V
CBO
=1500V
• Low Saturation Voltage : V
CE(sat)
=3V(Max.)
• High Speed : tf=0.2µs(Typ.)
• Collector Metal (Fin) is Fully covered with Mold Resin
Maximum Ratings (Ta=25°C)
TT2062
CHARACTERISTIC SYMBOL RATING UNIT
Collector-Base Voltage
V
CBO
1500 V
Collector-Emitter Voltage
V
CEO
800 V
Emitter-Base Voltage
V
EBO
5V
Collector Current
I
C
DC
Pulse
18
A
I
CP
35
Base Current
I
B
4A
Collector Power Dissipation
(Tc=25°C)
P
C
85 W
Junction Temperature
T
j
150 °C
Storage Temperature Range
T
stg
SYMBOL
RATING
B
1500
1500
6
75
12.5
-40
+150
-40
+150
1.65
cat T
j
=120 °C
UNIT
-55
150
°C
DMV1500M
CHARACTERISTIC
V
RSM
V
Transient Peak Reverse Voltage
V
RM
V
Peak Reverse Voltage
I
F(AV)
A
Average Forward Current
I
FSM
APeak Surge Forward Current
I
2
tA
2
s
I
2
t Limiting Value
T
j
°C
Junction Temperature
T
stg
V
F
°C
V
Storage Temperature
Forward Voltage Drop
cat I
F
=1A
T
j
=25 °C
us
Revene Recovery Time
