UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual 3
Chapter 1: UDC-5212 Universal Digital Clock
Installation
General
This UDC-5212 Universal Digital Clock has been carefully inspected,
tested, calibrated, and aligned before shipment to insure years of
trouble-free operation. Please check the equipment for any visible
damage which may have occurred in shipping.
Clock Mounting
The UDC-5212 Universal Digital Clock is designed for wall mounting.
Rack mounting kits are optional.
The rear panel of the UDC-5212 is provided with four rubber feet and
four keyholes. These are dimensioned for #8 screws. The rear panel is
recessed for connectors and to allow the clock to be placed close to the
wall.
Table 1-1 provides information about the UDC-5212 clock wall
mounting and clearance specifications. The minimum clearances, are
measured in inches from the mounting keyhole centers to the outside
edge of each clock
Note
A convenient template drawing showing the correct mounting centers
is included with the clock.
Rack Mounting
The UDC-5212 clock can be rack mounted with the optional rack
mounting kit. The kit is installed by removing the back panel side
screws, placing the rack mount in position, and reinstalling the screws.
The rack mount kits are designated as 5212RM.
Table 1-1. Clock Wall Mounting and Clearance Specifications
Overall
Dimensions
Mounting Keyhole
Centers
Clearances
(Inches)
14.0×14.0×3.375 in. 12.0×10.5 in. (4 keyholes)
• Top edge 1.125
• Sides 1.0
• Bottom edge 2.375
