26 UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual
Chapter 2: DTD-5225 Series Digital Time/Date Display
Controls
Mechanical
Table 2-15. Controls
Item Specification
Output timecode format SMPTE/EBU
Secondary reference Internal or power line
Second LEDs Single step or continuous sweep
Aux. offset Requires one of the following system
clock drivers:
• MTG-3901
• CSD-3901/3902
•CSD-5300
Date display M/D/Y or D/M/Y
Requires one of the following system
clock drivers:
• MTG-3901
• CSD-3901/3902
•CSD-5300
Local offset Any amount, user selectable
Display 12 or 24 hour format, H:M:S or M:S:F
Table 2-16. Mechanical Specifications
Item Specification
Style Wall-mount
Face diameter 11.5 in. (292 mm)
Overall dimensions 14.0×14.0×3.375 in. (356×356×86 mm)
