UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual 17
Chapter 2: DTD-5225 Series Digital Time/Date Display
Installation
Before installing the clock, see the DTD-5225 Quick Setup Instructions
included with this product.
General
Your DTD-5225 Digital Time/Date Display Clock has been carefully
inspected, tested, calibrated, and aligned before shipment to insure
years of trouble-free operation. Please check the equipment for any
visible damage which may have occurred in shipping.
Clock Mounting
The DTD-5225 Digital Time/Date Display Clock is designed for wall
mounting. Rack mounting kits are optional.
The rear panel of the DTD-5225 is provided with four rubber feet and
two keyholes. These are dimensioned for #8 screws. The rear panel is
recessed for connectors and to allow the clock to be placed close to the
wall. The clocks overall dimensions are listed in the “Specifications” on
page 25.
Note
A convenient template drawing showing the correct mounting centers
is included with the clock.
Rack Mounting
The DTD-5225 clock can be rack mounted with the optional rack
mounting kit. The kit is installed by removing the back panel side
screws, placing the rack mount in position, and re-installing the screws.
The DTD-5225 requires two rack units of height (2 RU) or 3.5 inches.
Rear Panel
The rear panel is provided with two spring-loaded speaker-type
connectors. Depending on the configuration, these may be used to
accept the serial timecode (SMPTE or EBU) or may be used as the
timecode output terminals. A label indicates whether the clock is in
Master or Slave configuration. All clocks are shipped configured for
timecode input (slave) operation, unless otherwise specified when
ordering. A standard AC power connector and cord are also included.
