22 UDC-5212 and DTD-5225 Digital Time/Date Display Clocks Installation and Operation Manual
Chapter 2: DTD-5225 Series Digital Time/Date Display
DIP switch 5 is used to select the output timecode format: either
SMPTE (non-Drop Frame) or EBU.
Brightness Adjustment
The digit’s brightness is incrementally adjusted by holding the
MANUAL SET and either the CW or CCW buttons simultaneously.
Holding MANUAL SET and CW increases the brightness one level
per second, while holding MANUAL SET and CCW decreases the
brightness. There are 16 levels of brightness.
