Imax B6 - NiCd;NiMH Cycle Programs; Lead-Acid Battery Programs

Battery
type
DEC
NiCd Sensitivity
D.Peak Default
NiCd Sensitivity
D.Peak Default
NIMH CYCLE
DCHG>CHG 3
DCHG 1 1314mAh
CHG 1 1430mAh
NIMH 1.0A 7.42V
D>C 022:45 00890
-
Batt type
Stop
Elapsed
time
INC
+
Discharge
or charge
current
Battery
voltage
DEC
Start
Enter
-
‘>3 seconds’
INC
+
Discharged
or charged
capacity
You can set up sequence on the
left and the number of cycles on
the right. You can balance, refresh
and break-in the battery with this
function .You can set a temporary
cool-off procedure in the user's
setting. Range of the cycle number
is 1-5.
Press BATT TYPE/STOP key to
stop program, you can press
START/ENTER key to alter charge
current. The sound indicates the
end of program.
When it approaches to the end,
you can see the capacity of the
battery being charged or
discharged. You can press INC or
DEC key to display result of each
cycle.
This program is only suitable for charging Pb lead-acid battery with
nominal voltage from 2 to 20V. Pb lead-acid battery is completely
different from NiCd/NiMH battery. These batteries can only deliver current
lower in comparison to their capacity. The same restriction applies to the
charging process. Consequently, the optimum charge current can only be
1/10 of the capacity. Pb battery can not be used for fast-charging, please
follow the instructions provided by the battery manufacturer.
You can press START/ENTER key to make it blink and alter the value of
parameters using INC or DEC key, press START/ENTER key to store the
value.
Pb lead-sulphuric acid battery program
Charge/discharge and discharge/charge cycle of
NiCd/NiMH battery
