Imax B6 - Program Status and Monitoring Displays; End Voltage and Cut-Off Status; Port Selection and Temperature; Input and Cell Voltage Monitoring

DEC
DEC
DEC
DEC
DEC
End Voltage
12.6v(3s)
Capacity Cut-Off
On 5000mAh
Safety Timer
ON 200min
USB/Temp Select
USB Enabled
Ext.Temp 26C
IN Power Voltage
12.56V
4.14 4.16 4.09
0.00 0.00 0.00
It comes to the final voltage when the
program ended.
3-pin connector is selected to be the USB
port.
The external temperature is displayed
when the temperature probe is used.
Present input voltage.
The battery is connected with each port
through cable; you can check voltage of
each cell in the battery pack. When the
cable is connected with the ports on the
right of the charger, the program will
display voltage of up to 6 batteries. The
battery pack needs an output connector
connected with each cell.
