30
INSTALLERUSER
MAINTENANCE TECHNICIAN
3.16 TECHNICAL DATA.
DIM 2 zone
ErP
DIM 3 zone
ErP
DIM H-LT
ErP
DIM H-2LT
ErP
Maximum nominal pressure bar 3 3 3 3
Maximum operating pressure °C 90 90 90 90
Low-temperature circuit minimum set-point regulation temper-
ature
°C -- -- 25 or 35 25 or 35
Low-temperature circuit maximum set-point regulation temper-
ature
°C -- -- 50 or 75 50 or 75
Low-temperature safety thermostat intervention °C -- -- 55 55
Water content in device l 1.3 1.7 1.5 1.9
Total head available in direct zone with 1000 l/h ow rate (max.) kPa (m c.a.) 31.40 (3.20) 31.40 (3.20) 31.40 (3.20) 29.20 (2.98)
Total head available in mixed zone (mixing valve open) with 1000
l/h ow rate (max.)
kPa (m c.a.) -- -- 30.30 (3.10) 30.30 (3.10)
Empty device weight kg 17.3 19.8 19.7 23.2
Full device weight kg 18.6 21.5 21.2 25.1
Electrical connection V/Hz 230/50 230/50 230/50 230/50
Maximum input A 0.62 0.95 0.62 0.95
Installed electric power W 100 135 100 135
Power in stand-by W 1.2 1.2 1.2 1.2
EEI value - ≤ 0.23 - Part. 2 ≤ 0.23 - Part. 2 ≤ 0.23 - Part. 2 ≤ 0.23 - Part. 2
Electric plant protection - IPX5D IPX5D IPX5D IPX5D
Maximum distance between boiler - DIM m 15 15 15 15
