Immergas EOLO Mini - D.h.w. flow switch; D.h.w. exchanger

12
STEMkW Special ed 01/08 EOLO Mini kW Special
Technical DocumentationTechnical Documentation
1
2
3
1
1
Primary
circuit
ow
Primary
circuit
return
D.h.w. ow switch (2).
Whenever domestic hot water is drawn at a rate of at least 1.5
l/min and a dynamic pressure of 0.3 bar, the ow switch (2)
enables the boiler to work in the d.h.w. mode.
is is done by means of a magnet that, lifting when hit by the
ow of domestic cold water, moves near to an electrical contact
(reed relay) causing it to move thanks to the magnetic eect.
When the contact closes, which is located outside the pipe
through which the water ows, it enables the adjustment board
to start the domestic hot water priority phase.
It consists of two parts (one in brass and one in plastic) that are
coupled together and locked with a pin.
A G1/4” thread on its body connects it to the lling unit
(3).
An 7.1 l/min (2 bar) for model 24 and a 9.2 l/min (2 bar) ow
limiter (1) for model 28 is installed at the ow switch exit.
D.h.w. exchanger.
It is a water-water exchanger made of stainless steel plates one
on top of the other - 14 (for model 24) and 16 (for model 28)
- on whose surface the boiler circuit water and the domestic
cold water ow in counter current and through which the heat
exchange takes place between the two lots of water.
e hydraulic coupling is done using four O rings (1) so it
can be connected directly to the d.h.w. inlet body and to the
d.h.w. outlet body.
D.h.w.
outlet
Cold
water
inlet
Cold
water inlet
