Programming the integrated P.C.B..
If wanted, some of the EOLO Mini kW Special boiler’s para-
meters can be programmed.
By modifying these parameters the boiler can be adapted to
your own specic requirements.
To access programming, put the main selector switch on Reset
for 15 to 20 seconds (LEDs 2 and 3 will start ashing simul-
taneously after about 10 seconds - wait for them to stop and put
the main selector switch on d.h.w. and c.h.).
Now put the main selector switch back on d.h.w.-c.h. ( ).
Once programming is activated, you enter the rst level where
you can choose the parameter you want to set.
e latter is indicated by the fast ashing of one of the LEDs
between 1 and 8.
Select by turning the d.h.w. temperature knob.
Consult the following table for the LED/parameter associa-
tion:
List of parameters LED ashing (fast)
Minimum heating output LED 1
Maximum heating output LED 2
Central heating ignitions timer LED 3
Central heating output supply ramp LED 4
Central heating ignitions delayed due
to room thermostat or Remote Control
requests (CAR or CRD)
LED 5
Domestic hot water thermostat LED 6
Circulator operation LED 7
Operating gas LED 8
Boiler mode
(NOT TO BE USED)
(it establishes whether the boiler works in
the instant or storage mode)
Led 8 e 1
Once you have chosen the parameter to change conrm selec-
tion by temporarily turning the main selector switch round to
RESET until the LED relative to the parameter switches o
and then release it.
When the ok has been given for the selection, go to the second
level where the value of the parameter selected can be set.
e value is indicated by the slow ashing of one of the LEDs
between 1 to 8.
e value is selected by turning the central heating tempera-
ture knob.
To exit the programming mode, do nothing for 30 seconds
or, if you are on the “parameter setting” level, put the main
selector switch on position .
For the association of the LED to the value, see the following
tables:
Heating output.  e boiler is made and calibrated in the cen-e boiler is made and calibrated in the cen-
tral heating phase at nominal output. In addition, it features
an electronic adjustment that adapts boiler potential to the
home’s actual heating requirements.
is means that the boiler works normally in a variable eld
of gas pressures, ranging from minimum to maximum output
depending on the system’s heating load.
NOTE: selection of the “Minimum heating output” and
“Maximum heating output” parameters, when there is a cen-
tral heating request, allows boiler ignition and powering of
the modulation with current equal to the value of the relative
parameter selected.
Minimum heating output
(continuous variation)
LED ashing
(slow)
0% Imax. (Standard setting) LED 1
7% Imax. LED 2
14% Imax. LED 3
21% Imax. LED 4
28% Imax.
LED 5
35% Imax. LED 6
42% Imax. LED 7
63% Imax. LED 8
Maximum heating output
(continuous variation)
LED ashing
(slow)
0% Imax. LED 1
11% Imax. LED 2
22% Imax. LED 3
33% Imax. LED 4
44% Imax. LED 5
55% Imax. LED 6
88% Imax. LED 7
100% Imax. (Standard setting) LED 8
