33
STEMkW Special ed 01/08 EOLO Mini kW Special
Technical Documentation
Technical Documentation
Permanent timing reduction. e boiler is tted with an
electronic timer that prevents the burner igniting too frequently
in the central heating phase.
e boiler is supplied with a timer as a standard feature, set
at 180 seconds.
Central heating ignitions timer
(continuous variation)
LED ashing
(slow)
30 seconds LED 1
55 seconds LED 2
80 seconds LED 3
105 seconds LED 4
130 seconds LED 5
155 seconds LED 6
180 seconds (Standard setting) LED 7
255 seconds LED 8
Central Heating ramp timing. e boiler supplies the maxi-
mum output set in the previous parameter.
e boiler executes an ignition ramp of about 650 seconds to
go from minimum to nominal central heating output.
Central heating ignitions timer
(continuous variation)
LED ashing
(slow)
65 seconds LED 1
130 seconds LED 2
195 seconds LED 3
390 seconds LED 4
455 seconds LED 5
520 seconds LED 6
585 seconds LED 7
650 seconds (Standard setting) LED 8
Central heating ignitions delayed due to Room thermostat
or Remote control requests (CAR or CRD). e boiler is set
to turn on immediately after a request.
In the case of particular systems (i.e. zone systems with mo-
torised thermostat valves, etc.) it might be necessary to delay
ignition.
Central heating ignitions delayed due to
Room thermostat or Remote control requests
(continuous variation)
LED ashing
(slow)
0 seconds (Standard setting) LED 1
54 seconds LED 2
131 seconds LED 3
180 seconds
LED 4
206 seconds LED 5
355 seconds LED 6
400 seconds LED 7
510 seconds LED 8
Domestic hot water thermostat. If the “correlated” thermostat
is set the boiler switches o according to the temperature set
with the d.h.w. adjustment knob.
While if the “xed” d.h.w. thermostat is set, switching o
temperature is set at 85°C regardless of what position the
knob is in.
Domestic hot water thermostat
LED ashing
(slow)
Correlated
LED 1
Fixed (Standard setting)
LED 8
Circulator function. Two circulator functioning modes can
be selected in the central heating phase.
In the “intermittent” mode, it is activated either by the Remote
control or eventual by the room thermostat, in the “continua-
tive” mode the circulator works all the time when the main
selector switch by Remote control is on heating.
Circulator function
LED ashing
(slow)
Intermittent (Standard setting) LED 1
Continuous
LED 8
Gas G110 – China Gas. e setting of this function serves to
adjust the boiler to work with the gases of the rst family.
Gas G110 - China Gas (rst family gas)
LED ashing
(slow)
O (Standard setting) LED 1
On LED 8
