EOLO Mini 28 kW Special technical data.
- e ue temperature values refer to an air inlet temperature
of 15°C.
- Data relative to d.h.w. performance refer to a dynamic inlet
pressure of 2 bar and an inlet temperature of 15°C; these
values are measured at boiler outlet considering that to nd
these declared values mixing with cold water is necessary.
- Maximum sound power emitted when the boiler is working
is < 55dBA. is measurement refers to tests in a semi free
eld with the boiler working at full power and with the
extension of the ue accessories complying with product
standards.
Nominal heat input
Minimum heat input
Nominal (useful) heat output
Minimum (useful) heat output
Eciency at nominal heat output
Eciency at 30% nominal heat output
Casing losses with burner On/O
Chimney losses with burner On/O
kW (kcal/h)
kW (kcal/h)
kW (kcal/h)
kW (kcal/h)
%
%
%
%
30.0 (25782)
12.0 (10356)
28.0 (24080)
10.5 (9030)
93.4
90.7
0.5 / 0.57
6.1 / 0.08
G20 G30 G31
Gas nozzle diameter
Supply pressure
mm
mbar (mm H
2
O)
1.30
20 (204)
0.77
29 (296)
0.77
37 (377)
Maximum working pressure of central heating circuit
Maximum working temperature of central heating circuit
Central heating temperature range
Total volume of system expansion vessel
Expansion vessel factory-set pressure
Appliance water content
Available head at 1000 litres/hours ow rate
Hot water production useful heat output
* Hot water hot water adjustable temperature
Hot water circuit ow limiter
Hot water circuit min. pressure (dynamic)
Hot water circuit max. working pressure
Min. draw of hot water
Specic ow rate (ΔT 30°C)
Continuous service capacity (ΔT 30°C)
Loaded boiler weight
Empty boiler weight
bar
°C
°C
l
bar
l
kPa (m H
2
O)
kW (kcal/h)
°C
l/min
bar
bar
l/min
l/min
l/min
kg
kg
3
90
35 - 85
4.5
1.0
2,9
25.90 (2.64)
28.0 (24080)
38 - 77
9.2
0.3
10
1.5
12.9
13.5
37.4
34.5
Power supply connection
Nominal power input
Installed electric power
Pump comsumption
Fan comsumption
Appliance electric insulation rating
V/Hz
A
W
W
W
-
230/50
0.85
155
85
52
IPX4D
G20 G30 G31
Flue ow rate at nominal heat output
Flue ow rate at minimum heat output
CO
2
at Q. Nom./Min.
CO at 0% of O
2
at Q. Nom./Min.
NO
X
at 0% of O
2
at Q. Nom./Min.
Flue temperature at nominal heat output
Flue temperature at minimum heat output
kg/h
kg/h
%
ppm
ppm
°C
°C
63
66
6.8 / 2.45
82 / 84
110 / 90
107
87
64
67
7.8 / 2.8
108 / 90
162 / 91
108
86
65
67
7.5 / 2.8
52 / 70
153 / 105
106
87
NO
X
class
Weighted NO
X
Weighted CO
-
mg/kWh
mg/kWh
2
151
56
Type of appliance C12 / C32 / C42 / C52 / C62 / C82 / B22 / B32
Category II 2H3+
