Immergas VICTRIX 20 Plus - VICTRIX Plus Control Panel Overview; Boiler Control Panel; Storage Tank Control Panel

6
STVP ed 02/06 VICTRIX Plus
VICTRIX Plus control panel.
Legend:
1 - Central heating ON light
2 - Central heating temperature selector switch
3 - D.h.w. temperature selector switch
4 - D.h.w. ON light
5 - D.h.w./Remote Control – D.h.w. and Heating switch 0
6 - Manometer
7 - Reset
8 - Temperature and diagnostics display
9 - Burner ON light
10 - Storage tank thermometer
11 - Cap
“Condensation Technology”.
Combustion performance (see VICTRIX).
Gas heating power (see VICTRIX).
Dewtemperature (see VICTRIX).
Operating performance of traditional boilers (see
VICTRIX).
Boiler control panel
Storage tank control panel
Operating performance of condensation boilers
(see VICTRIX).
Features and advantages of condensation boilers
(see VICTRIX).
