VICTRIX 24 kW X
Condensation wall-hung boiler for central
heating only which can be connected to a sepa-
rate storage tank.
VICTRIX 24 kW X
VICTRIX 24 kW X is a wall-hung room-sealed (type C) boiler
with a nominal heating input of 24 kW (20640 kcal/h) for
central heating only and designed, thanks to a kit (optional)
to be connected to a separate Storage tank with an 80, 105,
120 or 200 litre capacity.
e boiler, thanks to the condensation technology, stands out
for its particularly high performance and ample modulation
range (from 20% to 100 % of the rated output). e boiler is
equipped with a total premix combustion system that guar-
antees minimal polluting emissions and can run on either
natural gas or L.P.G.
e VICTRIX 24 kW X series of boilers is type-approved for
installation outside the building in a partly sheltered loca-
tion.
Note: By a partly sheltered location we mean a place where the
appliance is not exposed directly to the weather (rain, snow, hail,
etc.).
e boiler is adjusted and controlled by a microprocessor
controlled p.c.b. with continuous ame modulation which,
by means of a backlit display, shows boiler operating status
(temperatures, safety devices, etc.) and it also allows connection
(optional) to the Remote Control (with which you can easily
control the boiler remotely), to the external probe, to the zone
control unit and to the Multi-system Distribution Manifold.
e hydraulic circuit is equipped with a water-gas exchanger
with stainless steel heating coil and uses the new hydraulic unit
made in a composite material on which, besides the circulator,
the devices to control the hydraulic circuit are housed (the
General features.
system’s absolute pressure switch, 3-bar safety valve, automatic
system by-pass, etc.).
One of the boiler’s standard features is a antifreeze device
that protects against temperatures down to a minimum -5°C
(optional down to -15°C).
e VICTRIX 24 kW X boiler must be installed using the
intake/outlet kits or ducting systems (60 mm Ø rigid, 80 mm
Ø rigid, and 80 mm Ø exible) made of plastic and expressly
conceived and designed for Immergas condensation boilers.
