Immersion RC Vortex 230 Mojo - Flight Modes



Flight Modes
Three flight modes are configured by the Vortex Wizard, and are mapped by default to channel 5 of the R/C Tx.
These modes are as follows:
Acro
This mode is the preferred mode for the more advanced mini-quad pilot.
In many ways it is the simplest mode, but also the hardest mode to learn.

In Acro mode, the accelerometer part of the IMU is not used, only the Gyro.
Because of this, the quad will not self-level, explaining the steep learning curve for this mode.

To learn this mode, it is recommended to start flying the quad FPV, in Angle mode, get some
altitude, and switch into Acro mode.
Landings in Acro mode can be a bit challenging for the beginner, so switching to Angle mode
before landing is a reasonable way to deal with this.

Acro mode is the ideal mode to have fun with flips and rolls.
Angle
Angle mode is the easiest to learn. When the sticks are centered, the flight controller is always
working to level the quad.

The deviation of the Roll/Pitch controls from neutral defines the angle of the quad in flight.

Not a great mode for racing, but definitely the mode to use for the maiden flight.
Horiz
Horiz mode is a bit of a hybrid mode. It does auto-level, but also allows flips and rolls.




 



