SmartDock
®
Installation | User’s Guide
Installing the SmartDock
Into the Seat
The SmartDock ships with pre-installed mounting bolts, spacers, and locking nuts for
seat installation. The SmartDock uses the existing SCBA holder mounting brackets
that are supplied with SCBA compatible seats. Only install SmartDocks into
approved seats.
1. After removing the locknuts, place the SmartDock in the seat and check the
position of the pre-installed mounting bolts and spacers. If the pre-installed
hardware does not line up with the existing mounting holes, the upper and
lower bolts may be shifted in their respective mounting slots.
2. Align the mounting bolts with the desired holes in the seat and secure them to
the seat using the supplied 8mm threaded locking nuts. Using 13mm sockets,
torque all fasteners to 27 N-m.
Mounting the SmartDock
to the Vehicle
The SmartDock is supplied with pre-installed bolts and spacers for mounting directly
to the vehicle structure. Use only the supplied hardware.
1. Place the SmartDock in the desired location.
2. Remove and discard the nuts that are installed on the SmartDock mounting
bolts.
3. Align the two pre-installed 8mm threaded mounting bolts with the threaded
anchor points on the vehicle.
4. Using a 13mm socket, tighten mounting bolts to 27 N-m.
