IMMI SMARTDOCK - Tool List; SmartDock Parts

Claw
Assembly
Tool List
• T45 Torx Plus driver
• 13 mm sockets (2)
• Torque wrench capable of reading from 8 to 30 ft*lbs (10 to 40 N-m)
SmartDock Parts
Wing
Vertical
Support
Bracket
Claw
Height
Adjustment
Knob
Mounting
Hardware
Lower
Adjustment
Knob
6
SmartDock
®
Installation | User’s Guide
Lower
Claw
