Normal Usage Adjustment
During normal use, the SmartDock head must be raised or lowered to properly fit the
SCBA and ensure the safe functioning of the system. This is due to small differences
in SCBA air cylinder length that can affect the fit of individual SCBA air cylinders and
the SmartDock.
• If the head is too high, the SCBA air cylinder will seem loose in the SmartDock,
as the head will not be touching the top of the SCBA air cylinder. If severely
out of adjustment, the claw may seem like it stays open too long, and it may
be difficult to keep the pack, hoses and straps out during the insertion of the
SCBA.
• If the head is too low, the SCBA air cylinder will be difficult to insert and
the SmartDock head will require some force to completely close instead of
drawing the air cylinder in automatically. In some severe cases, the head may
not close at all.
To lower the SmartDock head, turn the height adjustment knob
counterclockwise as if you were trying to “unscrew” the knob.
To raise the SmartDock head, turn the height adjustment knob clockwise
as if you were trying to “tighten” the knob.
When tilting the cab for maintenance, it is recommended to remove SCBA packs from
the SmartDock.
