5.1.1 DISPLAYPANEL
Withtheuseofthedisplaypanel,youcancontrolandoverviewpumpmodes,on/offcontrol,pumpparameters
anderrors.Toseehowpumpmodeswork,seechapter5.2.Operation.

1. Bargraphdisplayofpumpparameters
2. Numericaldisplayofvalues
3. Unitdisplay
4. Displayofthecurrentlyselectedmode
5. Nightmode
6.
key
7.
key
8.
key






5.1.1.1 KEYFUNCTIONS
Key
Shortpress:
 Scrollingthroughparametersdownwardswhennotchangingparametervalues,
 Scrollingthroughmodesdownwardswhenmodeselectionisselected,
 Changingparametersdownwardswhensettingparametervalues.
Longpress:
 3secondstogetherwith
turnsonnightmode,
 3secondstogetherwith
lockspumpscurrentoperation,
 5secondstoturnoffpump,
 5secondstogetherwith
and keystorestorepumptofactorysettings.

Key
Shortpress:
 Toconfirmcurrentlyselectedvaluesofbothmodeandparameter.
Longpress:
 3secondstotriggermodeselection,
 3secondstogetherwith
lockspumpscurrentoperation,
