5.1.3 ANALOGINPUT/OUTPUT
OnlyavailableonNMT(D)MAXCpumps.

Thepumphasthreeanaloginputs/outputswithdifferentfunctions.Theycanbeconfiguredthroughtheweb
interface(page“pump”)orthroughModbus.
5.1.4 RELAYOUTPUT
OnlyavailableonNMT(D)MAXCpumps.
Configuration Description
Run Showswhenpumpisrunning.
Operate Showswhenpumpisstandby.
Error[Default] Showswhenpumphasanerror.
Nofunction Relayoutputdoesn’tshow anything.
Alwayson Relayalwaysclosed.
5.1.5 ETHERNET
OnlyavailableonNMT(D)MAXCpumps.
ThepumphasabuiltinwebserverwhichallowsyoutoaccessyourpumpdirectlyviaanexistingEthernet
connection.Thedefaultaddressforaccesstothepumpis"nmtpump/"or192.168.0.245/
ThewebserverusesHTMLpagestoset/view:
 Regulationmodesettings
 Regulationparameters(power,RPM,head,flow)
 Relaysettings
 Externalcontrolinputssettings
 Currentandpreviewserror
 Pumpstatistics(powerconsumption,runtimeandother)



Input/Output Function Function description
SET1 Run[Default ‐ Mode 1]
Turningthepumpon/off.Bydefaultactivatingwithconnectionto
SET3.
SET2 Max/Min[Default ‐ Mode 1]
Setthepumptomax.settingswhenSET1isactiveandtomin.
settingswhenSET1isinactive.
SET3 FB[Default ‐ Mode 1]
10V voltageoutputusedforactivatingSET1andSET2by
connectingthemtoSET3.
