IMT 3203i User Manual

8 IMT Electric-Hydraulic Crane Operation & Safety Manual # 99903618
Crane Component Identification
IMT electric-hydraulic cranes are designed to lift a variety of materials. These cranes are
typically mounted on a vehicle chassis, but they can have stationary mounts. Instructions on
how to operate the crane may refer to various crane components. Use the crane layout to help
you identify the appropriate crane components.
SNATCH
BLOCK
HOOK
ASSEMBLY
BASE
LOWER
CYLINDER
WINCH
LOWER
BOOM
EXTENSION
BOOM
Model 6006i has a power arm to help lift larger loads.
SNATCH
BLOCK
HOOK
ASSEMBLY
BASE
LOWER
CYLINDER
WINCH
LOWER
BOOM
EXTENSION
BOOM
POWER
ARM
