Inalto ICG905W - Testing Appliance Operation; Post-Installation Testing Procedure

22
After installation, test the appliance and ensure
that it operates correctly before handing it over
to the customer. The following procedure is
recommended:
• Turn on the gas and electricity supply
and attempt ignition on all burners, both
separately and in combination.
(For correct procedure refer to page 8).
Note that additional time needs to be allowed
for the initial lighting as air has to be purged
from the pipes.
• Observe the ame appearance on each
burner (Figure 9). If it is much larger or
much smaller than expected, the injector
size and supply pressure require checking.
Where a ame is unsatisfactory, refer to the
Troubleshooting Guide (page 11) to correct the
fault. If the Troubleshooting Guide does not
solve the problem, call the Service Centre.
• When all the foregoing is satisfactory, check
the turndown (minimum or low) setting on
each burner, as this may need adjustment.
Valves have a bypass controlling screw, which
may be accessed by removing the knob. This
screw will be located on a particular area of
the valve (refer Figure 10). Normally, this will
have been correctly set at the factory for use
on Natural Gas (NG) and should not require
adjustment.
IMPORTANT: If the appliance has been
converted to LPG, then the bypass screw will
HAVE to be screwed in until a small, stable
ame results.
Please ensure the supply pressure has been
checked PRIOR to any adjustment.
• If the appliance cannot be adjusted to
perform safely inform the customer of the
problem and ax an appropriate warning
notice to the appliance. If the fault appears
to be dangerous the appliance should be
disconnected. If a minor fault exists, the
customer may wish to use the appliance while
awaiting service.
If a fault cannot be xed, please call the
Service Centre.
• The customer should be advised that, in the
event of a fault, the local service organisation
or the retailer from whom the appliance was
purchased should be contacted.
• When satised that the unit is operating
correctly, turn o and instruct the customer
on correct operation as outlined in this
booklet. Ask the customer to operate the
controls to ensure that the correct procedure
is understood.
CAUTION: Servicing must only be carried out by
an authorised service person.
Injector sizes required for various gas types are
shown in Table 3 (page 19). The appliance test
point pressure for each gas type is also shown.
For model identication after installation, an
additional data plate sticker has been provided.
This sticker is to be stuck onto adjacent
cabinetry.
Testing Appliance
Operation
