20
This appliance is supplied set up for Natural
Gas usage. A conversion kit is included with the
product for Universal LPG usage. The conversion
kit contains the appropriate injectors, 1 Dual Gas
Regulator (which incorporates a Test Point) and
1 LPG sticker.
Please follow the procedure below if a
conversion to suit UNIVERSAL LPG is required:
• Remove the hotplate trivets, burner caps
and burner crowns to access the hotplate
injectors. Replace the factory tted injectors
with the appropriate injectors, as supplied
Refer to injector orice table for injector
sizes. The injector size is stamped on the side
of the injector.
• Follow the steps within this User Manual
to set the Dual Gas Regulator for LPG and
connect using approved gas thread tape or
compound to the elbow tting.
• Turn on the gas supply and at each new
connection check for leaks using soapy water.
Each hotplate valve should be turned on, one
at a time, and the injector hole blanked o for
several seconds.
• With the appliance operating check the outlet
pressure when all burners of the appliance
are operating at maximum, when the smallest
burner of the appliance is operating at
minimum.
Under these conditions the outlet pressure
should not vary from the nominal outlet
pressure of 2.60kPa by more than ±0.52kPa.
• If the regulator appears to not be performing
satisfactorily then check the following points:
• If the outlet pressure is consistently too low
then the inlet pressure may be too low and
adjustment of an upstream regulator may be
needed, or an upstream regulator or valve
with insucient ow capacity may be present
in the gas supply line.
• If this is suspected then it may be necessary
to repeat the checks whilst measuring both
the inlet and outlet pressure to determine if
the inlet pressure is in the range
2.75 – 7.00kPa.
• One by one, turn the knobs to minimum and
screw in the bypass screw (accessible when
the knob is removed) until a small stable
ame results; a length of 3-4mm. Turn the
knob to maximum and then back to minimum
to ensure that the correct minimum ame is
maintained.
• Attach the LPG sticker to the cooker, near the
gas supply inlet. Cover the Natural Gas label
that is factory tted.
LPG Conversion
