Inalto ICG905W - Checking Gas Supply and Pressure

19
CHECKING THE GAS SUPPLY
• Check the manometer zero point is correct.
• Connect the manometer to the cooktop pressure point. This is located on the regulator.
• Turn on the gas supply and electricity and try to ignite the gas.
NOTE: It will take additional time to light the gas for the rst time as air needs to be purged
from the pipes.
With the appliance operating check the outlet pressure:
• When all burners of the appliance are operating at maximum,
• When the smallest burner of the appliance is operating at minimum.
Under these conditions the outlet pressure should not vary from the nominal outlet pressure
of 1.00kPa by more than ±0.20kPa.
If the regulator appears to not be performing satisfactorily, then check the following points:
• If the outlet pressure is consistently too low then the inlet pressure may be too low and
adjustment of an upstream regulator may be needed, or an upstream regulator or valve
with insucient ow capacity may be present in the gas supply line. If this is suspected
then it may be necessary to repeat the checks whilst measuring both the inlet and outlet
pressure to determine if the inlet pressure is in the range 1.13 – 5kPa.
• Check that the regulator has been tted to the gas supply line in the correct orientation,
the arrow on the base of the body indicates the direction of gas ow.
Once these checks have been completed, if the regulator still fails to perform in a satisfactory
manner it should be replaced.
TABLE 3
Burner Type Natural Gas
(Nominal Test point pressure: 1.00kPa)
LPG
(Nominal Test point pressure: 2.75kPa)
Injector Size
(mm)
Gas Consumption
(MJ/h)
Injector Size
(mm)
Gas Consumption
(MJ/h)
Auxiliary burner 0.85 1.8–3.8 0.53 1.8–3.7
Semi Rapid burner 1.16 3.24–6.5 0.72 3.24–6.6
Rapid burner 1.49 5.4–10.8 0.93 5.4–11.0
Wok burner 1.80 6.3–14.4 1.07 6.3–14.7
