27
Register
Address:
Decimal
[hex]
Class & Type Function: Binary Format:
44097
[1000]
Class:
Configuration
Type:
Read\write
Operating mode
00000000000mmmmm
LSBs (mmmmm
)
(see list of modes on page 34)
44353
[1100]
Class:
Configuration
Type:
Read\write
Number of taps 000000000nnnnnnn
7-bit number (in binary)
44354,
44355
[1101,
1102 ]
Class:
Configuration
Type:
Read\write
Degrees per
segment
seeeeeeeemmmmmmm MSW
mmmmmmmmmmmm LSW
IEEE 754-1985 single precision float
MSW = [1101] LSW = [1102]
44356
[1103]
Class:
Configuration
Type:
Read\write
Number of
neutrals
000000000000nnnn
LSBs (nnnn)
Up to 8 neutrals, in binary.
If field value > 8, clamps to 8
44357
[1104]
Class:
Configuration
Type:
Read\write
Neutral start
segment
ssssssssssssssss
16 bits, first neutral tap
44358
[1105]
Class:
Configuration
Type:
Read\write
Display
“r”&“L”
000000000000000d
LSB(d
)
0 = disabled
1 = enabled
44867
[1302]
Class:
Configuration
Type:
Read\write
Preset tap
ssssssssssssssss
16 bits, preset tap no.
44868
[1303]
Class:
Configuration
Type:
Write-only
Load/clear
preset control
00000000000000cc
LSBs (cc)
00 – no operation
01 – clear offset
10 – load preset
