Page 23 - 2 Tank Sentinel Setup Programming Guide
TPI PUMP Menu(s)
AUTO - CONFIGURATION NOTE
The AUTO CFG function is used to invoke
the routines which query the TPI for the
number of pump controllers attached to
the TPI and other controller and pump
related information.
When AUTO CFG is started, the tank
gauge to scans the TPI for all pump
controllers attached to the TPI. For each
controller found, a corresponding pump
number will be displayed (e.g. if the TS-
TPI finds two controllers, there will be a
Pump 1 and a Pump 2). Their types will be
stored in the TYPE menu configuration
variable and the number of controllers will
be stored in the NO. PUMPS configuration
variable.
The Auto-Configuration process will
automatically update the following READ
ONLY configuration settings:
• NO. PUMPS (in System Menu)
• PUMP TYPE
• PUMP GROUP
• PUMP ADDRESS
• GROUP TYPE
M1 M2 M3 M4
TPI PUMP
AUTOCFG PUMP 1 PUMP 2
— Please confirm the system recognized the correct number of pumps —
— Press the CANCEL key three times to return to the System Menu —
— Use the “Number of Pumps” menu, which is described on the next page —
• AUTO CFG (user entry)
• NO. PUMPS “READ ONLY”
• PUMP N Menu(s) (both)
M1 M2 M3 M4
AUTO CFG (user entry)
The main TPI menu shows ENABLE, PUMP and
GROUP ....
Press the
M2
key to display the PUMP menu.
The TPI PUMP menu only shows AUTO CFG ....
Press the
M1
key to start the AUTO CFG process.
The TPI PUMP menu now shows AUTO CFG,
PUMP 1, PUMP 2, ....
