Reconciliation Setup Page 7 - 1
7
7 Reconciliation SETUP PROGRAMMING
Reconciliation Menu
H U
MENU
× Press this key and follow the
7
highlighted sequence below
Reconciliation Notes
This menu only appears when two conditions
exist:
• The ATG configuration displays an ‘R’
• The number of
Meters
is greater than zero
The ‘R’ stands for ‘Reconciliation’ and is part
of the configuration when a TS-DIM unit is
interfaced with the ATG. This option is
programmed into the ATG at the factory, only
when ordered and specially purchased.
The number of Meters is setup under the
SYSTEM menu as described in Chapter 1 of
this guide.
The purpose of this menu is to setup a
schedule to tell the ATG when and at what
time to start Reconciliation.
INCON recommends the times coincide with
either the time a site closes (end of day) or at
the time each shift ends (end of shift).
RECONCILIATION
SCHEDULE Press
M1
key.
— Continued on next page —
▼ Press the
DOWN
key one or two times ...
SETUP MENU (MORE)
EXIT SYSTEM TANKS PROBES
SELECT MENU OPTION
SETUP
UPGRADE LANGUAGE DATALOG
M1 M2 M3 M4
Contents:
Reconciliation Menu
See the Table of Contents to find topics in
this manual. See the Preface for general
information about this manual. And see the
Installation, Operator’s, TroubleShooting
Guides, and Application Notes for other
reference material.
SETUP MENU (MORE)
PRODUCTS RECONCILE DIM REPORTS
M1 M2 M3 M4
RECONCILIATION
SCHEDULE TIME
M1 M2 M3 M4
To Next Page
