Diagnostic Menu Page 28 - 1
28
28 Diagnostic Menu
DIAG Menu
H U
MENU
× Press this key and follow the
7
highlighted sequence below
Contents:
Diag Menu
Diag Navigation &
Descriptions
TPI Diagnostic Function Notes
RESET Menu
DIPSW Menu
CALIBRT Menu
Calibration Procedure
❋ The
DIAG
menu appears
only
when the optional
feature TPI is enabled and AUTO CFG has been
performed.
DIAG Navigation & Descriptions
Follow these navigation steps to display the
DIAG menu:
Press the
M2
key below DIAG to show the
PUMPS menu.
Press the
M1
key under PUMPS to display the
SELECT PUMP menu.
The SELECT PUMP menu displays all of the pump
numbers that are communicating with the Tank
Sentinel.
Press the
(M)
key under each pump number to
display the SELECT DIAGNOSTIC OPTION menu.
In this example, press the
M1
key for the PUMP 1
options.
Here is the DIAGNOSTIC OPTION menu showing
menu names for the three available functions.
— proceed to the next section - TPI
Diagnostic Function Notes —
SELECT MENU OPTION (MORE)
SETUP UPGRADE LANGUAGE DATALOG
Press the
DOWN
▼ key once ....
NOTE
☞
M1 M2 M3 M4
M1 M2 M3 M4
SELECT PUMP (MORE)
PUMP 1 PUMP 2 PUMP 3 PUMP 4
SELECT MENU OPTION
DISPLAY DIAG
M1 M2 M3 M4
SELECT DIAGNOSTIC OPTION
RESET DIPSW CALIBRT
M1 M2 M3 M4
To Next Page
