DIM Setup Page 8 - 3
8
DIM menu (Continued... FROM PREVIOUS PAGE)
(In most applications using one TS-DIM unit, keep these default settings)
FUEL PTS Press
M2
key.
FUELING POINTS
FUEL P N Press
M1
key.
FUELING PT N
DIM UNIT Press
M1
key.
DIM UNIT NUMBER - FUEL PT N
1
Enter the TS-DIM unit number connected to this
fueling point.
Use keypad to input a number.
Press
ENTER
to accept this data.
DIM FL PT Press
M2
key.
DIM FUELING POINT - FUEL PT N
1
1 - 16
Use keypad to input a number.
Press
ENTER
to accept this data.
— Press the CANCEL key to display the FUELING POINTS Menu —
— Repeat the above setup steps for each FUELING POINT —
— Press the CANCEL key to display the DISPENSER INTERFACE Menu —
DIMS Press
M3
key.
DIMS
DIM N Press
M1
key.
DIM N
ADDRESS Press
M1
key.
DIM ADDRESS - DIM N
1
1 - 8 Enter the same number as the jumper
location found inside the TS-DIM unit.
Use keypad to input a number.
Press
ENTER
to accept this data.
— Press the CANCEL key to display the DIMS Menu —
— Repeat the above setup steps for each DIM number —
— Press the CANCEL key 2 times to display the main SETUP Menu —
