SCM Setup (Console Programming)
The following instructions will guide you through SCM programming only. Administrator privileges will be necessary to
program the SCM application for the T5 FMS console. For instructions on FMS programming or on how to obtain an
Administrator access level, please refer to the T5 FMS Programming Guide (p/n 000-2142).
Access the T5 FMS console (via the LCD or Tank Sentinel Anyware - TSA) and navigate to the Setup Menu. Once at the
Setup Menu, go to each of the following sections and adjust SCM parameters accordingly. You will be prompted to enter
the Administrator access level when it is required.
Note: Sites setups vary depending on products used and other equipment installed. Setup information in the sections of
this chapter depict a typical site and are meant as examples only.
AC Input Module
The AC Input Module can accept incoming dispenser hook control signals. Hook signals are used to activate the STP via
the relay channel connected to the pump controllers. Control signals from the dispenser tell the console which product is
requested by the dispenser, then control signals activate the appropriate STP. To perform tests accordingly, SCM needs to
know when pumps/dispensers are being used by other applications.
Parameter Parameter Value
Active High If set to Yes, a high signal level will activate the channel and a low signal will deactivate the channel. If
set to No, then the channel is inverted and will only become active when a signal is absent and inactive
when a signal is present.
Channels Only select the total number of inputs intended for use.
Enabled If yes, will allow the channel to be mapped to another module. Other modules may use this signal to
trigger an event.
Name Should be a specic device from which the signal is originated.
Number Gasoline Hooks
per Dispenser
The number of product hook signal inputs to the console from the dispensers.
Example: AC Input Module SCM Setup
Group Name Parameter Name Parameter Value
AC Input Modules Number Gasoline Hooks per Dispenser 2
Module ‘#’ Channels ‘#’
Channel ‘#’ Name Disp 1 Unleaded Hook Signal
Enabled Yes
Active High Yes
Channel ‘#’ Name Disp 2 Unleaded Hook Signal
Enabled Yes
Active High Yes
Channel ‘#’ Name Disp 3 Unleaded Hook Signal
Enabled Yes
Active High Yes
