Incon TS-5000 User Manual

9
Example: Relay Module SCM Setup
Group Name Parameter Name Parameter Value
Relay Modules
Module ‘#’ Channels ‘#’
Channel ‘#’ Name Unleaded Solenoid Valve
Enabled Yes
Type Solenoid
Polarity Normal
Logic OR Logic
Physically Wired As Normally Open
Number of inputs 1
Input ‘#’ Type 4-20mA Input Module
Channel Unleaded SCCM Vacuum Sensor
Channel ‘#’ Name Premium Solenoid Valve
Enabled Yes
Type Solenoid
Polarity Normal
Logic OR Logic
Physically Wired As Normally Open
Number of inputs 1
Input ‘#’ Type 4-20mA Input Module
Channel Premium SCCM Vacuum Sensor
Channel ‘#’ Name Diesel Solenoid Valve
Enabled Yes
Type Solenoid
Polarity Normal
Logic OR Logic
Physically Wired As Normally Open
Number of inputs 1
Input ‘#’ Type 4-20mA Input Module
Channel Diesel SCCM Vacuum Sensor
