Indel B SW CUBE 12V User Manual

In order to connect the flexible tubing (B)
of
“CUBE”
it is sufficient to click the nozzles’
winglets (C)
into the grooves of the various
components.
In order to disconnect the tubing, press down on
the nozzles’ winglets (C)
and pull back at the
same time.
When choosing the path of the tubing it is important to choose the shortest one: in general it is preferable for the
tubing to be short rather than long.
Also, the num
ber of curves should be the smallest possible and the curving radii should be large: it is preferable
to have few and large curves rather than many and tight curves; the air passage is eased in this manner.
Pay attention so as to not create any creases or crimped areas.
32
SW CUBE 12V
SW_CUBE_12V_20-02-2019
