Indramat TDA 1 - Overview of Technical Data

29
• DOK-DIAX01-TDA********-PRJ1-EN-E1,44 • 07.97
Designation Symbol Unit
Cooling principle with air inside control cabinet
Link circuit rated voltage U(DC) (V) 300 300
Current rating I(typ.) (A) 50 100
Continuous effective current I(cont) (A) 35 70
Power consumption
(bus for control voltage)
+ 24V load voltage I(+UL) (A) 1.2 1.4
± 15V test voltage I(±UM) (mA) 160 160
Weights
Weight of controller m (kg) 10.5 10.5
Operating conditions
permissible ambient temperature
range at nominal ratings (° Celsius) +5° to +45°
max. permissible ambient
temperature at reduced ratings (° Celsius) +55°
storage and transportation temperature (° Celsius) -30° to +85°
max. altitude without limitation
of nominal ratings 1000 meters above sea level
permissible humidity
of air as per humidity class F as per DIN 40 040
protection type IP 10 as per DIN 40 050
2.5. Overview of
technical data
aus ENA7A-KDA3/TechnDaten/209-0042-4105-03
TDA 1-050 - 3 - • • •
TDA 1-100 - 3 - • • •
2. Control cabinet design
Fig. 19: TDA 1 - technical data
