2.6. Type codes
1. Designation: TDA
2. Series: 1
3. Version: 1
4. Rated current
50 A 050
100 A 100
5. DC link circuit rated voltage:
DC 300V: 3
6. Command value:
analog +/- 10V A
digital (16-bit parallel) D
SERCOS interface L
7. Additional encoder input:
without additional encoder input O
with additional encoder input for spindle feedback
or 2nd motor feedback signal P
with additional encoder input and synch. input
(exclusively with AS 35 and speed command value = A) Y
8. Additional interface :
without additional interface O
position command , digital (16 bit parallel) D
serial interface (RS 232 C) S
incremental encoder output I
Type code fields: TDA 1 3 - 100 - 3 - A00
Example:
fonte dati: INN 07.02
2. Control cabinet design
Fig. 20: TDA 1 - type codes
