3. Programming Module AS
Type code fields:
AS 53 / 004 - 000
Example:
3.4. Type codes
1. Designation: AS
2. Main spindle controller
KDA 3.2 3
RAC 2.2 5
RAC 3.1 6
TDA 1 7
RAC 4.1 8
KDA 3.3 13
RAC 2.3 15
RAC 3.5 16
RDA 1.3 17
RAC 4.3 18
3. Software code number
main spindle drive (standard)
(all combinations not listed below) 1
Servo drive (always with incremental encoder output) 2
Main spindle drive with incremental encoder output 3
(not with AS1••/..)
Main spindle drive with SERCOS interface 4
Main spindle drive with additional functions
(not with AS1••/..) 5
Servo drive with SERCOS interface 6
4. Motor feedback
high-resolution motor feedback 0
5. Code number of motor/controller combination
Determined and documented by INDRAMAT e.g. 04
6. Version
Standard 000
Customised, e.g.: 003 003
Quellverweis: Inn 07.20
Fig. 22 : Type code of programming module AS
