7. Assembly
Fig. 27: Installation sketch
Montage.fh3
Mounting panel or control
cabinet rear wall
Allen screwdriver 906q/SW5x400-46185
part number 221 672
(available on request)
Socket head cap screw
M6-DIN 912
(Allen screw)
