TOTAL LOAD PER RAIL / TETHERING HOOK (DOOR)
UPPER UTILITY RAIL LOWER UTILITY RAIL
Front Door 99 lb. (45 kg.) 33 lb. (15 kg.)
Rear Door 77 lb. (35 kg.) 44 lb. (20 kg.)
Rear Quarter
Panel
88 lb. (40 kg.) N/A
WARNING:
The Exterior Utility Belt is not to be used while
your Grenadier is
being driven. It is only for use
when parked.
It is not to be used to secure items on the roof.
Failure to follow these instructions and
precautions may result
in serious injury and
death.
Access Ladder (If equipped)
An Access Ladder
may be mounted on the back of your Grenadier.
The maximum load capacity for the Access Ladder is 330 lbs . It is
not for securing cargo. It is for access to the roof.
Never use the Access Ladder unless the 30/70 split doors are
completely closed.
Do not use the Access Ladder to secure cargo.
WARNING: Failure to follow these instructions and
precautions could result in serious injury and death.
CARGO LOADING AND SECURING
97
