CHILD
WITH INBUILT HARNESS
USE
USING IN-BUILT HARNESS
Ensure the restraint has been installed and set up as
per “Set Up” and “Installation” (Refer page 10 - 13)
“LIFT” the harness adjuster (A) to lengthen the
harness (see gure 1) whilst grasping both shoulder
harness straps and pulling. Ensure shoulder straps
are pulled equally on each side.
Place child in car seat with legs either side of the
crotch strap, place harness over the shoulders and
hips and engage the two buckle tongues “CLICK”
into buckle. Check it is properly engaged. Ensure
child is placed centrally in the seat.
Pull harness adjuster strap (B) to take the slack out of
the shoulder straps (see gure 2), until it is a rm but
comfortable t. Ensure buckle is adjusted centrally in
relation to the child. Adjust if necessary.
Step 1:
Step 2:
Step 3:
Step 4:
TO RELEASE CHILD
To release your child from the restraint simply press
the belt buckle and lift the shoulder straps from the
childs shoulders and carefully remove your child from
the seat. It is not necessary to release the Safe Grip
(red belt clamp), to remove your child.
When the restraint is not in use, the seat belt should
be fastened around it and engaged.
Figure 1
Figure 2
Always use a lap or lap-sash seat belt and upper anchorage strap to attach the child
restraint to the vehicle.
Do not use the restraint without the upper anchorage strap correctly attached and adjusted.
Do not use on any vehicle seat which faces sideways or rearwards.
IF AN AIRBAG IS FITTED IN THE SEATING POSITION WHERE THE CHILD RESTRAINT
IS TO BE FITTED, FOLLOW THE VEHICLE MANUFACTURER’S WARNINGS AND
INSTRUCTIONS.
DO NOT LEAVE CHILDREN UNATTENDED IN THE CAR.
Fit the harness rmly to the child.
A LOOSE RESTRAINT OR HARNESS IS DANGEROUS.
WARNING
!
PULL TO
LENGTHEN
PULL TO
LENGTHEN
“LIFT” TO
LENGTHEN
Harness
adjuster (A)
“PULL” TO
TIGHTEN
Harness
adjuster
strap (B)
WARNING
!
15
